Equipaer Industria Aeronautica Ltda.

Banner Target AV-1TAS-TC

Air-to-air banner target used for gunnery training. Made of highly resistant nylon mesh, a towing triangle and a stabilizer mast, and with a round central target in black for long distance visibility.

Description

• Developed to operate with and without the use of the air-target container AV-CAA, as the carrying aircraft can take-off with the open target directly from the ground
• Its nylon mesh allows training with 50mm and 7.62mm projectiles
• Can be used in a wide variety of combat aircrafts
• The target can be recovered and may be re-used depending on the number of hits and the ground operating area conditions
• Total weight: 12kg

Banner Target AV-2TAE-BR

Air-to-air banner target used for gunnery training. Made of high-resistant nylon mesh with 9mm opening, a towing triangle and a fiber glass stabilizer mast, which incorporates a radar reflector.

Description

• Developed to operating with the use of the air-target container AV-CAA
• In two color versions (red and white) for the use in different geographic, weather and visibility conditions
• Its nylon mesh allows training with 20mm and 30mm projectiles
• Can be used in a wide variety of combat aircrafts
• The target can be recovered and may be re-used depending on the number of hits and the ground operating area conditions
• Total weight: 31 kg

Acoustic System Target AV-5TAE

Air-to-air tetra plane target applied for gunnery training, used in combination with the acoustic target device. This target system allows real-time scoring feedback, enhancing training efficiency. The tetra plane target contains a radar reflector in an aluminum and fiber glass structure. The acoustic target includes an electronic device protected by a fiber glass mast. A ground device receives the firing performance result, process the information, and gives real time scoring results.

Description

• The acoustic system allows the use of 20mm to 30mm projectiles
• The system operates using the air-target container AV-CAA
• Can be used in a wide variety of combat aircrafts
• The system comprises an acoustic transmitter, noise generator, microphone, antenna and batteries
• The target can be recovered and may be re-used depending on the number of hits and on the ground operating area conditions

 Air-to-Ground Targets

Air-to-ground banner target made of resistant nylon mesh, framed with water-resistant canvas and straps for assembling and scaffolding. With a round central target in black for long-distance visibility.

Description

• Developed for leveled bombing and ground attack training exercises
• Allows the training of helicopters and aircrafts pilots
• It can be assembled vertically, for lateral shooting training as well as horizontally, in sandboxes, for top-down shooting training.
• Its nylon mesh allows training with 20mm, 30mm and 50mm projectiles
• It is possible to develop customized target sizes to answer to specific training needs

Sizes Available:

• AV-2TTE – 6.0m x 6.0m
• AV-3TTE-BN – 7.0m x 2.9m

EQ-LMF-70/7 - HL 08

Aluminum body weapon to launch 7 (seven) 2.75“ MK4, MK40 (SBAT70) folding fin aerial rocket (FFAR)

• Suitable for use on high and low speed aircrafts, including helicopters
• Compatible with any aircraft provided with 14 “ NATO standard lug system
• Designed as a dual-purpose weapon for either air or surface targets
• Replaceable electronic intervalometer for pulse and continuous electric current systems
• Provides single and ripple fire modes
• Load versatility, being capable to operate with one to seven rockets, at any position, under any firing mode
• Weight (empty): 25 kgfin aerial rocket (FFAR)

EQ-LMF-70/7 - AP 09

Reusable, composite material body rocket launcher designed to carry and to launch seven 2.75 inch MK4, MK40 (SBAT70) folding fin aerial rocket (FFAR).

Description

• Suitable for use on high and low speed aircrafts, including helicopters
• Compatible with any aircraft provided with 14" NATO standard lug system
• Designed as a dual-purpose weapon for either air or surface targets
• Replaceable electronic intervalometer for pulse and continuous current systems
• Provides single and ripple fire modes
• Load versatility, being capable to operate with one to seven rockets, at any position, under any firing mode
• Cylindrical construction of seven aluminum replaceable launching tubes and a removable forward fairing
• Weight (empty): 47 kg

EQ-LMF-70/7 - AP - 1 10

Reusable, composite material body, dual proposal weapon to launch 7 (seven) 2.75“ MK66, Hidra70 wrap around folding fin aircraft rockets (WAFFAR) or MK4, MK40 (SBAT70) folding fin aerial rocket (FFAR).

Description

• Suitable for use on high and low speed aircrafts, including helicopters
• Compatible with any aircraft provided with 14" NATO standard lug system
• Designed as a dual-purpose weapon for either air or surface targets
• Replaceable electronic intervalometer for pulse and continuous current systems
• Provides single and ripple fire modes
• Load versatility, being capable to operate with one to seven rockets, at any position, under any firing mode
• Cylindrical construction of seven aluminum replaceable launching tubes and a removable forward fairing
• Weight (empty): 47 kg

EQ-LMF-70/19 11

Aluminum body weapon to launch 19 (nineteen) 2.75 “MK4, MK40 (SBAT70) folding fin aerial rocket (FFAR).

• Suitable for use on high and low speed aircrafts, including helicopters
• Compatible with any aircraft provided with 14“ Nato standard mounting lug system
• Designed as a dual-purpose weapon for either air or surface targets.
• Replaceable electronic intervalometer for pulse and continuous electric current systems
• Provides single and ripple fire modes
• Load versatility, being capable to operate with one to nineteen rockets, at any position, under any firing mode
• Weight (empty): 75 kg
• Tube length: 1.316 mm

EQ-MRL-32-70/7 12

Aluminum made, dual proposal weapon to launch 7 (seven) 2.75 “MK66, Hidra70 wrap around folding fin aircraft rockets (WAFFAR) or MK4, MK40 (SBAT70) folding fin aerial rocket (FFAR), both with the possibility to use fuzes and connector for smart weapon systems.

Description

• Multipurpose launcher, compatible with a wide range of rockets and war heads
• Suitable for use on high and low speed aircrafts, including helicopters
• Compatible with any aircraft provided with 14“ NATO standard lug system
• Designed as a dual-purpose weapon for either air or surface targets
• Replaceable electronic intervalometer for pulse and continuous electric systems
• Provides single and ripple fire modes
• Load versatility, being capable to operate with one to seven rockets, at any position, under any firing mode
• Cylindrical construction with a removable forward fairing
• 23-pin connector for the fuze setting circuit

EQ-MRL-32-70/19 13

Aluminum made, dual proposal weapon to launch 19 (nineteen) 2.75“ MK66, Hidra70 wrap around folding fin aircraft rockets (WAFFAR) or MK4, MK40 (SBAT70) folding fin aerial rocket (FFAR), both with the possibility to use fuzes and connector for smart weapon systems.

Description

• Multipurpose launcher, compatible with a wide range of rockets and war heads
• Suitable for use on high and low speed aircrafts, including helicopters
• Compatible with any aircraft provided with 14“ NATO standard lug system
• Designed as a dual-purpose weapon for either air or surface targets
• Replaceable electronic intervalometer for pulse and continuous current systems
• Provides single and ripple fire modes
• Load versatility, being capable to operate with one to seven rockets, at any position, under any firing mode
• Cylindrical construction with a removable forward fairing
• 23-pin connector for the fuze setting circuit

Air Target Transportation Container AV-CAA 14

Air-target transportation container is made of aluminum and was developed to carry, launch and tow the air-to-air targets and towing cable as well as to release the target system at the end of the mission. The AV-CAA is installed using the NATO standard 14“ suspension system of the towing aircraft.

Description

• Develop for air-to-air or ground-to-air training
• Can carry different types of air-targets and different lengths of towing cables
• Compatible electric circuit and cockpit control allowing the container to be used in a wide variety of combat aircrafts
• Reliable electrical system, using MIL-STD components
• Depending on the mission type and tow aircraft, the container can be used in combination with another container increasing the mission efficiency
• Removable nose to provide access to the front inner part of the container
• Safe operation with dual pyrotechnic system for ejecting and releasing
• Empty weight: 89 kg
• Distance between suspension lugs: 14”

  Logistic Transportation Container AV-CLS-51 15

  Logistic transportation container is made of aluminum and was developed to carry a wide range of supplies and materials. The EQ-CLS-51 is installed using the NATO standard 14“ suspension system of the aircraft.

  Description

  • The container has two side windows, back door and removable nose for easy access to the inner compartments
  • It includes internal nets designed to fasten the supplies and materials
  • Safety locks are used to close the removable nose and the access windows
  • Distance between suspension lugs: 14”
  • Empty weight: 80 kg
  • Load Capacity: 350 kg

  Bomb and Rocket Dispenser EQ-BRD-20 16

The bomb and rocket dispenser has been developed to answer the requirements of bombing and rocketry training and can carry four 2.75“ rockets and six practice bombs.

Description

• It includes both 14 and 30“ standard NATO mounting lugs
• It operates with MK4, MK40 (SBAT70) folding fin aerial rocket (FFAR)
• Bomb and rocket firing is programmed by use of two intervalometers, one for the rocket firing circuit and one for the bomb firing circuit
• The dispenser can be operated under single or ripple firing mode
• Weight (empty): 125 kg
• Rotary switch: 18-30 VDC

Missile Adaptor EQ-ALM 17

The missile adaptor is an aeronautic equipment designed to fix a 30 “ suspension system missile launcher to a 14“ NATO suspension system aircraft or device.

Description

• Develop to facilitate the installation of the missile launcher to the military aircraft
• Can be used in a wide variety of combat aircrafts and external load types
• Low dragging coefficient and high structural resistance
• Load capacity: 150 kg
